PP Series
Tread & Tyre Hardness ○ ○ ○ ● ○ 60° ± 5° Shore A
Temperature Resistance ○ ● ● ○ ○ -10℃ to +60℃
Rolling Resistance ● ● ● ● ● Excellent
Operating Noise ● ● ● ○ ○ Good
Floor Surface Preservation ● ● ● ○ ○ Good
Tread
Made of high quality polypropylene. A Polypropylene wheel offer good heat resistance, rigidity and toughness, fatigue resistance, stress crack resistance, and not affected by humidity environment.
It has a good corrosion resistance, oil resistance, and good resistant to chemical, solvent and other aggressive substances, moreover it is odorless and recyclable.
APP wheel also provide heavy load and small rolling resistance.
Working temperature: -10℃~+60℃.
Hardness: 65°±5°shore D.
Other features
· Shock-absorbing, Low rolling resistance
· Operating temperature: -10°C~+60°C
· Maintenance-free under normal conditions.
Specification
| Item No. | Wheel Diameter (D)【mm】 |
Wheel Width (T2)【mm】 |
Load Capacity 【kg(lbs)】 |
Axle Bore Ø(d)【mm】 |
Hub Length (T1)【mm】 |
Tread Profile |
| 12022951080200 | 38 | 16.5 | 20kg (44lbs) | 6 | 20.5 | Round |
| 12022902006200 | 50 | 21 | 25kg (55lbs) | 6.2 | 24 | |
| 12022952081200 | 65 | 25 | 30kg (66lbs) | 6 | 30.5 | |
| 12022952004100 | 65 | 25 | 30kg (66lbs) | 8 | 30.5 | |
| 12022952130100 | 62.5 | 35 | 30kg (66lbs) | 10.2 | 39 | |
| 12022903131500 | 76 | 32 | 35kg (77lbs) | 10.2 | 39.5 | |
| 12022903137100 | 75 | 25 | 35kg (77lbs) | 8 | 30 | |
| 12022904151400 | 100 | 35 | 90kg (198lbs) | 13 | 35 | |
| 12022904154100 | 100 | 35 | 90kg (198lbs) | 13 | 35 | |
| 12022904100100 | 100 | 25 | 90kg (198lbs) | 8 | 30.5 | |
| 12022905201300 | 125 | 48 | 100kg (220lbs) | 10.2 | 54.5 | |
| 12022905130100 | 125 | 35 | 100kg (220lbs) | 13 | 39 | Flat |
