1102 Series — B Type Caster
Swivel easily under heavy load, ideal for heavy-duty workshop trucks in automobile, glass, textile industries, etc. Patented thread guards and dust covers prevent swivel failure caused by build-up of strings between the wheel and fork legs, as well as the dust in the wheel bearing.
Features
Center Lock Brake
Thread guard specially for textfile industry
(optional)
Metal Thread Guard
(optional)
Swivel W/Center lock
(AK type)
Plastic Thread Guard
(optional)
Different PU tread handness available
Features
.webp)
Center Lock Brake
.webp)
Thread guard specially for textfile industry(optional)
.webp)
Metal Thread Guard(optional)
.webp)
Swivel W/Center lock(AK type)
Plastic Thread Guard(optional)
.webp)
Different PU tread handness available
Wheel Options
-
PU on Cast
-
Rubber on Cast
-
NBR Rubber on Cast
-
Nylon
-
WMRC
-
QPU
-
PU on AL Core
-
CPD
-
Cast Iron
-
Non-marking
Rubber on Cast -
EQPU
-
PU on Cast
(2050A/2050B) -
ZQPU
(Dual Wheels) -
VPU
-
EPU
-
VQPU
-
VXPU on Iron Core
-
Recilent rubber
on AL Core -
Non - marking NBR Rubber on Cast
-
QPU on AL Core
Top Plate Size And Bolt Hole Spacing
| Suffix | Top Plate Size | Bolt Hole Spacing | Attaching Bolt Size |
| 4" | 90x120 mm (3-17/32" x 4-23/32") |
60 x 90 mm (2-3/8" x 3-17/32") |
11 mm (7-16") |
| 5,6,8" | 110 x 140 mm (4-11/32" x 5-1/2") |
75 x 110 mm (2-15/16" x 4-11/32") |
12 mm (1/2") |
| 110 x 140 mm (4-11/32" x 5-1/2") |
80 x 105 mm (3-5/32" x 4-1/8") |
12 mm (1/2") |
|
| 130 x 130 mm (5-1/8" x 5-1/8") |
105 x 105 mm (4-1/8" x 4-1/8") |
9 mm (3/8") |
|
| 130 x 130 mm (5-1/8" x 5-1/8") |
105 x 105 mm (4-1/8" x 4-1/8") |
12 mm (1/2") |
|
| 130 x 165 mm (5-1/8" x 6-1/2") |
100 x 130 mm (3-15/16" x 5-1/8") |
12 mm (1/2") |
|
| 114 x 159 mm (4-1/2" x 6-1/4") |
73.8 x 129.4 mm (2-29/32" x 5-3/32") |
12 mm (1/2") |
|
| 10" | 130 x 167 mm (5-1/8" x 6-9/16") |
85 x 140 mm (3-11/32" x 5-1/2" |
12 mm (1/2") |
| 110 x 175 mm (4-11/32" x 6-7/8") |
65 x 140 mm (2-9/16" x 5-1/2") |
12 mm (1/2") |
|
| 12" | 130 x 167 mm (5-1/8" x 6-9/16") |
85 x 140 mm (3-11/32" x 5-1/2") |
12 mm (1/2") |
Top Plate Size And Bolt Hole Spacing
| Suffix | Top Plate Size | Bolt Hole Spacing | Attaching Bolt Size |
| 4" | 90x120 mm (3-17/32" x 4-23/32") |
60 x 90 mm (2-3/8" x 3-17/32") |
11 mm (7-16") |
| Suffix | Top Plate Size | Bolt Hole Spacing | Attaching Bolt Size |
| 4" | 90x120 mm (3-17/32" x 4-23/32") |
60 x 90 mm (2-3/8" x 3-17/32") |
11 mm (7-16") |
| 5,6,8" | 110 x 140 mm (4-11/32" x 5-1/2") |
75 x 110 mm (2-15/16" x 4-11/32") |
12 mm (1/2") |
| 110 x 140 mm (4-11/32" x 5-1/2") |
80 x 105 mm (3-5/32" x 4-1/8") |
12 mm (1/2") |
|
| 130 x 130 mm (5-1/8" x 5-1/8") |
105 x 105 mm (4-1/8" x 4-1/8") |
9 mm (3/8") |
|
| 130 x 130 mm (5-1/8" x 5-1/8") |
105 x 105 mm (4-1/8" x 4-1/8") |
12 mm (1/2") |
|
| 130 x 165 mm (5-1/8" x 6-1/2") |
100 x 130 mm (3-15/16" x 5-1/8") |
12 mm (1/2") |
|
| 114 x 159 mm (4-1/2" x 6-1/4") |
73.8 x 129.4 mm (2-29/32" x 5-3/32") |
12 mm (1/2") |
|
| 10" | 130 x 167 mm (5-1/8" x 6-9/16") |
85 x 140 mm (3-11/32" x 5-1/2" |
12 mm (1/2") |
| 110 x 175 mm (4-11/32" x 6-7/8") |
65 x 140 mm (2-9/16" x 5-1/2") |
12 mm (1/2") |
|
| 12" | 130 x 167 mm (5-1/8" x 6-9/16") |
85 x 140 mm (3-11/32" x 5-1/2") |
12 mm (1/2") |
Specification
| Diameter × Width | Load | Material | Item No. | Bearing | Overall Height | Swivel Radius | ||
| Fixed | Swivel | Brake | ||||||
| 93mm x 28mm (3-21/32"x1-3/32") |
400kgs (880 lbs) |
Cast Iron | 1102-04-14-1 | 1102-04-14-2 | 1102-04-14-4 | Ball Bearing | 143.5mm (5-21/32") |
Swivel 87mm |
| 100mm x 32mm (4"x1-1/4") |
250kgs (550 lbs) |
Nylon |
1102-04-07-1 | 1102-04-07-2 | 1102-04-07-4 | Ball Bearing |
147mm (5-25/32") |
Swivel 92mm Swivel W/AK Lock Brake 148mm |
| 200kgs (440 lbs) |
CPD | 1102-04-49-1 | 1102-04-49-2 | 1102-04-49-4 | ||||
| 100mm x 34mm (4"x1-3/8") |
335kgs (735 lbs) |
QPU (Round) | 1102-04-80-1 | 1102-04-80-2 | 1102-04-80-4 | |||
| 385kgs (845 lbs) |
QPU (Flat) | 1102-04-80-1 | 1102-04-80-2 | 1102-04-80-4 | ||||
| 100mm x 36mm (4"x1-7/16") |
250kgs (550 lbs) |
PU on Cast | 1102-04-33-1 | 1102-04-33-2 | 1102-04-33-4 | |||
| 200kgs (440 lbs) |
Rubber on Cast | 1102-04-03-1 | 1102-04-03-2 | 1102-04-03-4 | ||||
| 250kgs (550 lbs) |
PU on AL Core (Round) | 1102-04-108-1 | 1102-04-108-2 | 1102-04-108-4 | ||||
| 300kgs (660 lbs) |
QPU on AL Core (Round) | 1102-04-87-1 | 1102-04-87-2 | 1102-04-87-4 | ||||
| 100mm x 38mm (4"x1-1/2") |
200kgs (440 lbs) |
NBR Rubber on Cast | 1102-04-04-1 | 1102-04-04-2 | 1102-04-04-4 | |||
| 200kgs (440 lbs) |
Non-marking Rubber on Cast |
1102-04-11-1 | 1102-04-11-2 | 1102-04-11-4 | ||||
| 200kgs (440 lbs) |
Non-marking NBR Rubber on Cast |
1102-04-90-1 | 1102-04-90-2 | 1102-04-90-4 | ||||
| 100mm x 40mm (4"x1-9/16") |
275kgs (600 lbs) |
PU on AL Core (Round) | 1102-04-108-1 | 1102-04-108-2 | 1102-04-108-4 | |||
| 200kgs (440 lbs) |
Recilent rubber on AL Core | 1102-04-89-1 | 1102-04-89-2 | 1102-04-89-4 | ||||
| 325kgs (715 lbs) |
QPU on AL Core (Round) | 1102-04-87-1 | 1102-04-87-2 | 1102-04-87-4 | ||||
| 100mm x 46.5mm (4"x1-13/16") |
335kgs (735 lbs) |
ZQPU (Dual Wheels) | 1102-04-101-1 | 1102-04-101-2 | 1102-04-101-4 | |||
| 122mm x 36.5mm (4-13/16"x1-7/16") |
600kgs (1320 lbs) |
Cast Iron | 1102-05-14-1 | 1102-05-14-2 | 1102-05-14-4 | Ball Bearing | 168.5mm (6-5/8") |
Swivel 103mm |
| Diameter × Width | Load | Material | Item No. | Bearing | Oceraall Height | Swivel Radius | ||
| Fixed | Swivel | Brake | ||||||
| 125mm x 40mm (5"x1-9/16") |
340kgs (750 lbs) |
PU on Cast | 1102-05-33-1 | 1102-05-33-2 | 1102-05-33-4 | Ball Bearing | 170mm (6-11/16") |
Swivel 107mm Swivel W/AK Lock Brake 158mm |
| 220kgs (485 lbs) |
Rubber on Cast | 1102-05-03-1 | 1102-05-03-2 | 1102-05-03-4 | ||||
| 300kgs (660 lbs) |
Nylon | 1102-05-07-1 | 1102-05-07-2 | 1102-05-07-4 | ||||
| 300kgs (660 lbs) |
PU on AL Core (Round) | 1102-05-108-1 | 1102-05-108-2 | 1102-05-108-4 | ||||
| 350kgs (770 lbs) |
QPU on AL Core (Round) | 1102-05-87-1 | 1102-05-87-2 | 1102-05-87-4 | ||||
| 250kgs (550 lbs) |
NBR Rubber on Cast | 1102-05-04-1 | 1102-05-04-2 | 1102-05-04-4 | ||||
| 250kgs (550 lbs) |
CPD | 1102-05-49-1 | 1102-05-49-2 | 1102-05-49-4 | ||||
| 250kgs (550 lbs) |
Non-marking Rubber on Cast | 1102-05-11-1 | 1102-05-11-2 | 1102-05-11-4 | ||||
| 250kgs (550 lbs) |
Non-marking NBR Rubber on Cast |
1102-05-90-1 | 1102-05-90-2 | 1102-05-90-4 | ||||
| 300kgs (660 lbs) |
Recilent rubber on AL Core | 1102-05-89-1 | 1102-05-89-2 | 1102-05-89-4 | ||||
| 450kgs (990 lbs) |
QPU (Round) | 1102-05-80-1 | 1102-05-80-2 | 1102-05-80-4 | ||||
| 500kgs (1100 lbs) |
QPU (Flat) | 1102-05-80-1 | 1102-05-80-2 | 1102-05-80-4 | ||||
| 340kgs (750 lbs) |
EPU (Round Shape) | 1102-05-78-1 | 1102-05-78-2 | 1102-05-78-4 | ||||
| 390kgs (860 lbs) |
EPU (Flat Shape) | 1102-05-78-1 | 1102-05-78-2 | 1102-05-78-4 | ||||
| 450kgs (990 lbs) |
EQPU (Round Shape) | 1102-05-81-1 | 1102-05-81-2 | 1102-05-81-4 | ||||
| 500kgs (1100 lbs) |
EQPU (Flat Shape) | 1102-05-81-1 | 1102-05-81-2 | 1102-05-81-4 | ||||
| 125mm x 50mm (5" x 2") |
400kgs (880 lbs) |
PU on AL Core (Flat) | 1102-05-108-1 | 1102-05-108-2 | 1102-05-108-4 | Ball Bearing | 170mm (6-11/16") |
1Swivel 107mm Swivel W/AK Lock Brake 158mm |
| 450kgs (990 lbs) |
QPU on AL Core (Flat) | 1102-05-87-1 | 1102-05-87-2 | 1102-05-87-4 | ||||
| 125mm x 51mm (5" x 2") |
450kgs (990 lbs) |
ZQPU (Dual Wheels) | 1102-05-101-1 | 1102-05-101-2 | 1102-05-101-4 | |||
| 138mm x 36.5mm (5-7/16"x1-7/16") |
700kgs (1540 lbs) |
Cast Iron | 1102-06-14-1 | 1102-06-14-2 | ─ | Ball Bearing | 191mm (7-17/32") |
Swivel 111mm |
| 150mm x 40mm (6"x1-9/16") |
350kgs (770 lbs) |
NBR Rubber on Cast | 1102-06-04-1 | 1102-06-04-2 | 1102-06-04-4 | Ball Bearing | 197mm (7-3/4") |
Swivel 119mm Swivel W/AK Lock Brake160mm |
| 400kgs (880 lbs) |
Nylon | 1102-06-07-1 | 1102-06-07-2 | 1102-06-07-4 | ||||
| 350kgs (770 lbs) |
CPD | 1102-06-49-1 | 1102-06-49-2 | 1102-06-49-4 | ||||
| 300kgs (660 lbs) |
Non-marking Rubber on Cast | 1102-06-11-1 | 1102-06-11-2 | 1102-06-11-4 | ||||
| 300kgs (660 lbs) |
Non-marking NBR Rubber on Cast | 1102-06-90-1 | 1102-06-90-2 | 1102-06-90-4 | ||||
| 350kgs (770 lbs) |
Recilent rubber on AL Core | 1102-06-89-1 | 1102-06-89-2 | 1102-06-89-4 | ||||
| 400kgs (880 lbs) |
WMRC | 1102-06-45-1 | 1102-06-45-2 | 1102-06-45-4 | ||||
| Diameter × Width | Load | Material | Item No. | Bearing | Oceraall Height | Swivel Radius | ||
| Fixed | Swivel | Brake | ||||||
| 150mm x 42mm (6"x1-5/8") |
410kgs (900 lbs) |
PU on Cast | 1102-06-33-1 | 1102-06-33-2 | 1102-06-33-4 | Ball Bearing | 197mm (7-3/4") |
Swivel 119mm Swivel W/AK Lock Brake 160mm |
| 400kgs (880 lbs) |
PU on AL Core (Round) | 1102-06-108-1 | 1102-06-108-2 | 1102-06-108-4 | ||||
| 450kgs (990 lbs) |
QPU on AL Core (Round) | 1102-06-87-1 | 1102-06-87-2 | 1102-06-87-4 | ||||
| 550kgs (1200 lbs) |
QPU (Round) | 1102-06-80-1 | 1102-06-80-2 | 1102-06-80-4 | ||||
| 600kgs (1320 lbs) |
QPU (Flat) | 1102-06-80-1 | 1102-06-80-2 | 1102-06-80-4 | ||||
| 500kgs (1100 lbs) |
VPU (Round) | 1102-06-82-1 | 1102-06-82-2 | 1102-06-82-4 | ||||
| 670kgs (1475 lbs) |
VQPU (Round Shape) | 1102-06-83-1 | 1102-06-83-2 | 1102-06-83-4 | ||||
| 800kgs (1760 lbs) |
XPU on Iron Core (Round) | 1102-06-91-1 | 1102-06-91-2 | 1102-06-91-4 | ||||
| 410kgs (900 lbs) |
EPU (Round Shape) | 1102-06-78-1 | 1102-06-78-2 | 1102-06-78-4 | ||||
| 460kgs (1010 lbs) |
EPU (Flat Shape) | 1102-06-78-1 | 1102-06-78-2 | 1102-06-78-4 | ||||
| 550kgs (1200 lbs) |
EQPU (Round Shape) | 1102-06-81-1 | 1102-06-81-2 | 1102-06-81-4 | ||||
| 600kgs (1320 lbs) |
EQPU (Flat Shape) | 1102-06-81-1 | 1102-06-81-2 | 1102-06-81-4 | ||||
| 150mm x 45.5mm (6"x1-13/16") |
260kgs (570 lbs) |
Rubber on Cast | 1102-06-03-1 | 1102-06-03-2 | 1102-06-03-4 | |||
| 150mm x 50mm (6" x 2") |
450kgs (990 lbs) |
PU on AL Core (Flat) | 1102-06(50)-108-1 | 1102-06(50)-108-2 | 1102-06(50)-108-4 | |||
| 500kgs (1100 lbs) |
QPU on AL Core (Flat) | 1102-06(50)-87-1 | 1102-06(50)-87-2 | 1102-06(50)-87-4 | ||||
| 150mm x 51mm | 550kgs (1210 lbs) |
ZQPU (Dual Wheels) | 1102-06-101-1 | 1102-06-101-2 | 1102-06-101-4 | Ball Bearing | 238mm (9-3/8") |
Swivel 154mm Swivel W/AK Lock Brake 179mm |
| 180mm x 44mm (7" x 1-3/4") |
450kgs (990 lbs) |
PU on AL Core (Round) | 1102-07-108-1 | 1102-07-108-2 | 1102-07-108-4 | |||
| 600kgs (1320 lbs) |
QPU on AL Core (Round) | 1102-07-87-1 | 1102-07-87-2 | 1102-07-87-4 | ||||
| 180mm x 50mm (7" x 2") |
450kgs (990 lbs) |
PU on Cast | 1102-07-33-1 | 1102-07-33-2 | 1102-07-33-4 | |||
| 600kgs (1320 lbs) |
QPU (Round) | 1102-07-80-1 | 1102-07-80-2 | 1102-07-80-4 | ||||
| 650kgs (1430 lbs) |
VPU (Round) | 1102-07-82-1 | 1102-07-82-2 | 1102-07-82-4 | ||||
| 650kgs (1430 lbs) |
XPU on Iron Core (Round) | 1102-07-91-1 | 1102-07-91-2 | 1102-07-91-4 | ||||
| 650kgs (1430 lbs) |
VQPU (Round Shape) | 1102-07-83-1 | 1102-07-83-2 | 1102-07-83-4 | ||||
| 193mm x 46mm (7-3/5"x1-13/16") |
300kgs (660 lbs) |
Rubber on Cast | 1102-08-03-1 | 1102-08-03-2 | ─ | Ball Bearing | 244.5mm (9-5/8") |
Swivel 159mm |
| 200mm x 44mm (8"x1-3/4") |
350kgs (770 lbs) |
NBR Rubber on Cast | 1102-08-04-1 | 1102-08-04-2 | 1102-08-04-4 | Ball Bearing | 248mm (9-3/4") |
Swivel 164mm Swivel W/AK Lock Brake 184mm |
| 350kgs (770 lbs) |
Non-marking Rubber on Cast | 1102-08-11-1 | 1102-08-11-2 | 1102-08-11-4 | ||||
| 350kgs (770 lbs) |
Non-marking NBR Rubber on Cast |
1102-08-90-1 | 1102-08-90-2 | 1102-08-90-4 | ||||
| 400kgs (880 lbs) |
Recilent rubber on AL Core | 1102-08-89-1 | 1102-08-89-2 | 1102-08-89-4 | ||||
| 200mm x 45.5mm (8"x1-13/16") |
550kgs (1200 lbs) |
Cast Iron | 1102-08-14-1 | 1102-08-14-2 | 1102-08-14-4 | |||
| Diameter × Width | Load | Material | Item No. | Bearing | Oceraall Height | Swivel Radius | ||
| Fixed | Swivel | Brake | ||||||
| 200mm x 50mm (8" x 2") |
450kgs (990 lbs) |
PU on Cast | 1102-08-33-1 | 1102-08-33-2 | 1102-08-33-4 | Ball Bearing | 248mm (9-3/4") |
Swivel 164mm Swivel W/AK Lock Brake 184mm |
| 450kgs (990 lbs) |
Nylon | 1102-08-07-1 | 1102-08-07-2 | 1102-08-07-4 | ||||
| 750kgs (1650 lbs) |
PU on Cast (2050A/2050B) | 1102-08-62-1 | 1102-08-62-2 | 1102-08-62-4 | ||||
| 400kgs (880 lbs) |
CPD | 1102-08-49-1 | 1102-08-49-2 | 1102-08-49-4 | ||||
| 450kgs (990 lbs) |
WMRC | 1102-08-45-1 | 1102-08-45-2 | 1102-08-45-4 | ||||
| 500kgs (1100 lbs) |
PU on AL Core (Round) | 1102-08-108-1 | 1102-08-108-2 | 1102-08-108-4 | ||||
| 550kgs (1200 lbs) |
PU on AL Core (Flat) | 1102-08-108-1 | 1102-08-108-2 | 1102-08-108-4 | ||||
| 650kgs (1430 lbs) |
QPU on AL Core (Flat) | 1102-08-87-1 | 1102-08-87-2 | 1102-08-87-4 | ||||
| 700kgs (1540 lbs) |
QPU on AL Core (Round) | 1102-08-87-1 | 1102-08-87-2 | 1102-08-87-4 | ||||
| 670kgs (1475 lbs) |
QPU (Round) | 1102-08-80-1 | 1102-08-80-2 | 1102-08-80-4 | ||||
| 720kgs (1580 lbs) |
QPU (Flat) | 1102-08-80-1 | 1102-08-80-2 | 1102-08-80-4 | ||||
| 670kgs (1475 lbs) |
VPU (Round) | 1102-08-82-1 | 1102-08-82-2 | 1102-08-82-4 | ||||
| 800kgs (1760 lbs) |
VQPU (Round Shape) | 1102-08-83-1 | 1102-08-83-2 | 1102-08-83-4 | ||||
| 1100kgs (2420 lbs) |
XPU on Iron Core (Round) | 1102-08-91-1 | 1102-08-91-2 | 1102-08-91-4 | ||||
| 650kgs (1430 lbs) |
EPU (Round) | 1102-08-78-1 | 1102-08-78-2 | 1102-08-78-4 | ||||
| 700kgs (1540 lbs) |
EPU (Flat Shape) | 1102-08-78-1 | 1102-08-78-2 | 1102-08-78-4 | ||||
| 750kgs (1650 lbs) |
EQPU (Round) | 1102-08-81-1 | 1102-08-81-2 | 1102-08-81-4 | ||||
| 800kgs (1760 lbs) |
EQPU (Flat) | 1102-08-81-1 | 1102-08-81-2 | 1102-08-81-4 | ||||
| 200mm x 51mm (8" x 2") |
650kgs (1430 lbs) |
ZQPU (Dual Wheels) | 1102-08-101-1 | 1102-08-101-2 | 1102-08-101-4 | |||
| Diameter × Width | Load | Material | Item No. | Bearing | Oceraall Height | Swivel Radius | ||
| Fixed | Swivel | Brake | ||||||
| 250mm x 50mm (10" x 2") |
400kgs (880 lbs) |
NBR Rubber on Cast | 1102-10-04-1 | 1102-10-04-2 | 1102-10-04-4 | Ball Bearing | 305mm (12") |
Swivel 175.5mm Swivel W/AK Lock Brake 187mm |
| 400kgs (880 lbs) |
Non-marking Rubber on Cast | 1102-10-11-1 | 1102-10-11-2 | 1102-10-11-4 | ||||
| 600kgs (1320 lbs) |
PU on Cast | 1102-10-33-1 | 1102-10-33-2 | 1102-10-33-4 | ||||
| 800kgs (1760 lbs) |
Nylon | 1102-10-07-1 | 1102-10-07-2 | 1102-10-07-4 | ||||
| 250mm x 62mm (10"x2-7/16") |
400kgs (880 lbs) |
NBR Rubber on Cast | 1102-10(62)-04-1 | 1102-10(62)-04-2 | 1102-10(62)-04-4 | Ball Bearing | 305mm (12") |
Swivel 175.5mm Swivel W/AK Lock Brake 187mm |
| 400kgs (880 lbs) |
Non-marking Rubber on Cast | 1102-10(62)-11-1 | 1102-10(62)-11-2 | 1102-10(62)-11-4 | ||||
| 600kgs (1320 lbs) |
PU on Cast | 1102-10-33-1 | 1102-10-33-2 | 1102-10-33-4 | ||||
| 400kgs (880 lbs) |
Non-marking NBR Rubber on Cast | 1102-10-90-1 | 1102-10-90-2 | 1102-10-90-4 | ||||
| 900kgs (1980 lbs) |
QPU (Round) | 1102-10-80-1 | 1102-10-80-2 | 1102-10-80-4 | ||||
| 900kgs (1980 lbs) |
QPU (Flat) | 1102-10-80-1 | 1102-10-80-2 | 1102-10-80-4 | ||||
| 1000kgs (2200 lbs) |
VPU (Round) | 1102-10-82-1 | 1102-10-82-2 | 1102-10-82-4 | ||||
| 1200kgs (2640 lbs) |
VQPU (Round Shape) | 1102-10-83-1 | 1102-10-83-2 | 1102-10-83-4 | ||||
| 1500kgs (3300 lbs) |
XPU on Iron Core | 1102-10-91-1 | 1102-10-91-2 | 1102-10-91-4 | ||||
| 300mm x 76mm (12" x 3") |
650kgs (1430 lbs) |
NBR Rubber on Cast | 1102-12-04-1 | 1102-12-04-2 | ─ | Ball Bearing | 352mm (13-27/32") |
Swivel 222mm |
| 550kgs (1200 lbs) |
Non-marking NBR Rubber on Cast | 1102-12-90-1 | 1102-12-90-2 | ─ | ||||
| 300mm x 90mm (12"x3-17/32") |
1250kgs (2750 lbs) |
VPU (Round) | 1102-12-82-1 | 1102-12-82-2 | ─ | Ball Bearing | 352mm (13-27/32") |
Swivel 222mm |
| 1500kgs (3300 lbs) |
VPU (Flat) | 1102-12-82-1 | 1102-12-82-2 | ─ | ||||
| 1500kgs (3300 lbs) |
VQPU (Round Shape) | 1102-12-83-1 | 1102-12-83-2 | ─ | ||||
| 1800kgs (3960 lbs) |
VQPU (Flat) | 1102-12-83-1 | 1102-12-83-2 | ─ | ||||
| 2000kgs (4400 lbs) |
XPU on Iron Core (Round) | 1102-12-91-1 | 1102-12-91-2 | ─ | ||||
| 2500kgs (5500 lbs) |
VXPU on Iron Core(Flat) | 1102-12-91-1 | 1102-12-91-2 | ─ | ||||
| 305mm x 70mm (12"x2-3/4") |
1000kgs (2200 lbs) |
PU on Cast | 1102-12-33-1 | 1102-12-33-2 | ─ | Ball Bearing | 354.5mm (13-31/32") |
Swivel 224mm |
| 1250kgs (2750 lbs) |
QPU (Flat) | 1102-12-80-1 | 1102-12-80-2 | ─ | ||||
