腳輪尺寸 |
底板尺寸 |
底板孔距 |
安裝尼帽尺寸 |
1-1/2″ |
38x46 mm (1-1/2″x1-13/16″) |
28x37 mm (1-1/8″x1-1/2″) |
5mm(1/5″) |
2″ |
47x59 mm (1-7/″8x2-1/3″) |
35x46 mm (1-3/8″x1-13/16″) |
6mm(3/16″) |
2-1/2″ |
57x70 mm (2-1/4″x2-3/4″) |
41x55 mm (1-5/8″x2-3/16″) |
8mm(5/16″) |
3″ |
57x70 mm (2-1/4″x2-3/4″) |
41x55 mm (1-5/8″x2-3/16″) |
8mm(5/16″) |
|
 |
| |
|
 |
|
 |
|
| |
| |
|
 |
|
|
腳輪尺寸 |
底板尺寸 |
底板孔距 |
安裝尼帽尺寸 |
1-1/2″ |
26x46 mm (1″x1-13/16″) |
15x37 mm (3/5″x1-7/16″) |
5mm(1/5″) |
2″ |
40x58 mm (1-9/16″x2-7/15″) |
25x46 mm (1″x1-13/16″) |
6mm(3/16″) |
2-1/2″ |
46x70 mm (1-13/16″x2-3/4″) |
28x55 mm (1-1/8″x2-3/16″) |
8mm(5/16″) |
3″ |
46x70 mm (1-13/16″x2-3/4″) |
28x55 mm (1-1/8″x2-3/16″) |
8mm(5/16″) |
|
|
| |
|
|
|
|
|
| |
| |
輪徑×輪寬 |
載重 |
材質 |
 型號 |
軸承 |
總高 |
固定 |
活動 |
剎 車 |
|
38mmx16mm
(1-1/2″x5/8″) |
20kgs(44lbs) |
塑料輪 |
1120-15-09-1 |
1120-15-09-2 |
-- |
中管 |
50mm
(2″) |
20kgs(44lbs) |
橡膠輪 |
1120-15-06-1 |
1120-15-06-2 |
-- |
25kgs(55lbs) |
尼龍輪 |
1120-15-07-1 |
1120-15-07-2 |
-- |
|
50mmx22mm
(2″x7/8″) |
25kgs(55lbs) |
塑料輪 |
1120-02-29-1 |
1120-02-29-2 |
-- |
中管 |
65mm
(2-9/16″) |
30kgs(66lbs) |
尼龍輪 |
1120-02-07-1 |
1120-02-07-2 |
-- |
25kgs(55lbs) |
橡膠輪 |
1120-02-06-1 |
1120-02-06-2 |
-- |
|
63mmx25mm
(2-1/2″x1″) |
30kgs(66lbs) |
塑料輪 |
1120-25-29-1 |
1120-25-29-2 |
-- |
中管 |
80mm
(3-1/8″) |
35kgs(77lbs) |
尼龍輪 |
1120-25-07-1 |
1120-25-07-2 |
-- |
|
75mmx25mm
(3″x1″) |
35kgs(77lbs) |
塑料輪 |
1120-03-29-1 |
1120-03-29-2 |
1120-03-29-4 |
中管 |
89mm
(3-1/2″) |
40kgs(88lbs) |
尼龍輪 |
1120-03-07-1 |
1120-03-07-2 |
1120-03-07-4 |
|
|
