APU系列

重型輪
PU外包+鋁芯
輪面

由高品質聚氨酯製成。得貹硬度92°的PU輪不僅能提供良好的地板保護作用,而且低噪音。得貹PU輪有著優秀的抗水解特性,是用熱帶地區及潮溼的工作環境。
特色

•抗化學、溶劑及侵蝕
•耐磨
•抗微生物
•適用環境溫度:-30°C~+70°C
•在正常使用情況下,無需維修
輪框

內框:鋁芯。


12035903130100 75 29 150kg (330lbs) 17 29 圓弧 精密滾珠軸承
12035903135300 75 30 150kg (330lbs) 12 32
12035903135171 80 30 180kg (396lbs) 12 32
12035903135271 80 30 180kg (396lbs) 15 32
12035904135171 100 31 230kg (507lbs) 15 32
12035904135271 100 31 230kg (507lbs) 17 32
12035904155171 100 36 325kg (716lbs) 12 36
12035904155271 100 36 325kg (716lbs) 15 36
12035904155371 100 40 350kg (771lbs) 12 40
12035904155471 100 40 350kg (771lbs) 15 40
12035905135171 125 31 280kg (617lbs) 15 32
12035905135271 125 31 280kg (617lbs) 17 32
12035905135371 125 40 350kg (771lbs) 15 40
12035905135471 125 40 350kg (771lbs) 17 40
12037005180100 125 40 350kg (771lbs) 20 19
12035906185171 150 42 450kg (991lbs) 17 42
12035906185271 150 42 450kg (991lbs) 20 42
12035956185171 160 42 500kg (1102lbs) 17 42
12035956185271 160 42 500kg (1102lbs) 20 42
12035907185171 180 44 600kg (1323lbs) 20 44
12035907185271 180 44 600kg (1323lbs) 25 44
12035908205171 200 50 800kg (1764lbs) 20 50
12035908205271 200 50 800kg (1764lbs) 25 50
12035902105100 50 25 100kg (220lbs) 17 50 平面
12035904205171 100 50 300kg (661lbs) 17 50
12035904205271 100 50 300kg (661lbs) 20 50
12035905205171 125 50 450kg (992lbs) 17 50
12035905205271 125 50 450kg (992lbs) 20 50
12035906205171 150 50 500kg (1102lbs) 17 50
12035906205271 150 50 500kg (1102lbs) 20 50
12035956205171 160 50 550kg (1213lbs) 17 50
12035956205271 160 50 550kg (1213lbs) 20 50
12035908185100 200 44 700kg (1543lbs) 20 44
12035908205371 200 50 800kg (1764lbs) 20 50
12035908205471 200 50 800kg (1764lbs) 25 50
