TW風硬輪/風硬省力輪系列
Soild Rubber Wheel
高負載, 用於重物搬運,行走寧靜,尤其適用於凹凸不平的路面及雜物較多的環境。
Heavy-duty with a cushion ride, ideal for uneven ground condition.
風輪(烤漆鐵框)
Pneumatic with
painted steel rim
風輪(塑框)
Pneumatic with
plastic rim
防爆輪
Flat Free Tire
風硬省力輪
Soild Rubber Wheel(EZ Roll)
防刺輪
PU Foam Tire
規格
Size
輪徑
Wheel
diamete
輪寬
Width
材質
Material
輪框
Rim
中寬
Hub Length
載重
Load
軸承
Bearing
軸承孔徑
Bore Size
型號
Item No.
輪子樣式
8"
(250-4)
198mm 51mm 風式硬輪(Q)
Soild Rubber Wheel(Q)
鐵框(烤漆)
Steel rim (painted)
50mm 正心
(2" centered)
100 kgs
(220 lbs)
滾珠
Ball Bearing
17mm 1243080015
200mm 53mm 風式硬輪
Soild Rubber Wheel
鐵框(烤漆)
Steel rim (painted)
55mm 正心
(2-1/5" centered)
120 kgs
(264 lbs)
滾珠
Ball Bearing
17mm 1243080077
鐵框(鍍鋅)
Steel rim (zinc-plated)
1243080019
塑框 Plastic rim 57.5mm 正心
(2-1/4" centered)
1243080068
200mm 53mm 風硬省力輪
Soild Rubber Wheel
(EZ Roll)
鐵框(鍍鋅)
Steel rim (zinc-plated)
55mm 正心
(2-1/5" centered)
120 kgs
(264 lbs)
滾珠
Ball Bearing
17mm 1243080079
208mm 53.5 mm 防爆輪
Flat Free Tire
鐵框(鍍鋅)
Steel rim (zinc-plated)
100 kgs
(220 lbs)
滾珠
Ball Bearing
17mm 1243080067
10"
(350-4)
250mm 68mm 風硬省力輪
Soild Rubber Wheel
(EZ Roll)
鐵框(烤漆)
Steel rim (painted)
65mm 正心
(2-9/16" centered)
180 kgs
(396 lbs)
滾珠
Ball Bearing
17mm 1243100070
鐵框(鍍鋅)
Steel rim (zinc-plated)
1243100069
255mm 85mm 防爆輪
Flat Free Tire
鐵框(鍍鋅)
Steel rim (zinc-plated)
65mm 正心
(2-9/16" centered)
150 kgs
(330 lbs)
滾珠
Ball Bearing
17mm 1243100049
257mm 79.5mm 風硬彈力輪
Soild Resilient
Rubber Wheel
鐵框(烤漆)
Steel rim (painted)
65mm 正心
(2-9/16" centered)
180 kgs
(396 lbs)
滾珠
Ball Bearing
17mm 1243100076
鐵框(鍍鋅)
Steel rim (zinc-plated)
1243100051
263mm 87mm 防刺輪
PU Foam Tire
鐵框(鍍鋅)
Steel rim (zinc-plated)
65mm 正心
(2-9/16" centered)
150 kgs
(330 lbs)
滾珠
Ball Bearing
17mm 1243100058
