AMR/AGV-6 強化美國輪-雙輪系列(中輕型)

AMR/AGV- 6 Pressed Steel Caster - Dual Wheel (Medium/Light Duty)

腳架采用高鋼性板材，配合熱處理珠道及高精密滾珠來達到極高的荷重與長時間的使用壽命，腳架旋轉靈活、同時確保低重心需求，輪面接觸地面大或雙輪結構，受力支撐更平穩使用更持久，適用於AMR/AGV (無人車)使用。

Pressed steel caster horn/housing designed to swivel easily under load. Heat-treated raceways guarantee longer service life during the AMR/AGV application. Low overall height and small offset characteristics are ideal for AMR/AGV industry.

全效雙輪
Resolute
(Dual Wheels)

ZQPU雙輪
ZQPU(Dual Wheels)

ZQPU雙輪(抗靜電)
ZQPU
(Dual A-Static Wheels)

尼龍輪
Nylon

金鋼輪
King Kong Wheel

*有其它抗靜電輪可供選擇，如有需求請聯絡工廠

*Other Anti-Statuc Wheels Available, Please Contact The Factory

編號 Suffix	底板尺寸 Top Plate Size	底板孔距 Bolt Hole Spacing	安裝尼帽尺寸 Attaching Bolt Size
2", 2.5", 3"	85 x 105 mm (3-5/16" x 4-1/8")	60 x 80 mm (歐規底板) 2-3/8"x3-1/4"(European Plate)	8 mm (5/16")
2", 2.5", 3"	95 x65 mm (3-3/4" x 2-1/2")	75 x 45 mm (3" x 1-3/4")	8 mm (5/16")


			固定 Fixed	活动 Swivel	煞车 Brake
50mm x 45mm (2" x 1-3/4")	200kgs (440lbs)	尼龍輪 Nylon	—	1165-02-07-2(6)	—	滾珠軸承 Ball Bearing	74mm (2-7/8")	48mm (1-7/8")
50mm x 45mm (2" x 1-3/4")	250kgs (551lbs)	金鋼輪 King Kong Wheel	—	1165-02-100-2(6)	—
50mm x 20mm(41.5) (2" x 3/4")	70kgs (154lbs)	ZQPU雙輪 ZQPU(Dual Wheels)	—	1165-02-101-2(6)	—
50mm x 20mm(41.5) (2" x 3/4")	70kgs (154lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-02-101-2(6)	—
50mm x 22.5mm (2" x 7/8")	60kgs (132lbs)	全效雙輪 Resolute(Dual Wheels)	—	1165-02-68-2(6)	—
50mm x 45mm (2" x 1-3/4")	200kgs (440lbs)	尼龍輪 Nylon	—	1165-02-07-2(6)	—	滾珠軸承 Ball Bearing	83.5mm (3-1/4")	56mm (2-1/4")
50mm x 45mm (2" x 1-3/4")	250kgs (551lbs)	金鋼輪 King Kong Wheel	—	1165-02-100-2(6)	—
50mm x 20mm(41.5) (2" x 3/4")	70kgs (154lbs)	ZQPU雙輪 ZQPU(Dual Wheels)	—	1165-02-101-2(6)	—
50mm x 20mm(41.5) (2" x 3/4")	70kgs (154lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-02-101-2(6)	—
50mm x 22.5mm (2" x 7/8")	60kgs (132lbs	全效雙輪 Resolute(Dual Wheels)	—	1165-02-68-2(6)	—
62.5mm x 45mm (2.5" x 1-3/4")	250kgs (551lbs)	尼龍輪 Nylon	—	1165-25-07-2(6)	—	滾珠軸承 Ball Bearing	90mm (3-1/2")	60mm (3-5/8")
62.5mm x 45mm (2.5" x 1-3/4")	450kgs (992lbs)	金鋼輪 King Kong Whee	—	1165-25-100-2(6)	—
62.5mm x 20mm(41.5) (2.5" x 3/4")	250kgs (551lbs)	ZQPU雙輪 ZQPU(Dual Wheels)	—	1165-25-101-2(6)	—
62.5mm x 20mm(41.5) (2.5" x 3/4")	200kgs (440lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-25-101-2(6)	—
62.5mm x 45mm (2.5" x 1-3/4")	250kgs (551lbs)	尼龍輪 Nylon	—	1165-25-07-2(6)	—	滾珠軸承 Ball Bearing	96mm (3-3/4")	68.5mm (2-3/4")
62.5mm x 45mm (2.5" x 1-3/4")	450kgs (992lbs)	金鋼輪 King Kong Wheel	—	1165-25-100-2(6)	—
62.5mm x 20mm(41.5) (2.5" x 3/4")	250kgs (551lbs)	ZQPU雙輪 ZQPU(Dual Wheels)	—	1165-25-101-2(6)	—
62.5mm x 20mm(41.5) (2.5" x 3/4")	200kgs (440lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-25-101-2(6)	—
75mm x 45mm (3" x 1-3/4")	300kgs (661lbs)	尼龍輪 Nylon	—	1165-03-07-2(6)	—	滾珠軸承 Ball Bearing	102.5mm (4")	75mm (3")
75mm x 45mm (3" x 1-3/4")	500kgs (1102lbs)	金鋼輪 King Kong Wheel	—	1165-03-100-2(6)	—
75mm x 20mm(41.5) (3" x 3/4")	300kgs (661lbs)	ZQPU雙輪 ZQPU(Dual Wheels)	—	1165-03-101-2(6)	—
75mm x 20mm(41.5) (3" x 3/4")	250kgs (551lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-03-101-2(6)	—
