AMR/AGV-3雙精密軸承活動腳輪系列(中型)

AMR/AGV-3 Double Precision Ball Bearing Caster (Medium Duty)

採用雙精密軸承，來應對 AMR/AGV 需求的複雜環境：耐久，長距離運行，防塵等特點；適用於中等載荷 AMR/AGV 用。

With two precision ball bearings embedded in the caster fork, this AMR/AGV-3 caster offer durability, dust-prevention and extended service life, compared to traditional stamping fabrication caster. AMR/AGV-3 caster is suitable for light and medium duty AMR/AGVs.

ZQPU雙輪
ZQPU (Dual Wheels)

QPU輪
QPU

鋁芯AQPU
QPU on AL Core

ZQPU輪(抗靜電)
QPU(Dual Anti-Static Wheels)

藍色彈力全效輪
Blue Resilient Resolute Rubber

W全效輪
W Resolute

*有其它抗靜電輪可供選擇，如有需求請聯絡工廠

*Other Anti-Statuc Wheels Available, Please Contact The Factory

底板尺寸 Top Plate Size	底板孔距 Bolt Hole Spacing	安裝尼帽尺寸 Attaching Bolt Size
60 x 92 mm (2-3/8" x 3-5/8")	45 x 75 mm (1-3/4" x 3")	8 mm (5/16")
85 x 110 mm (3-11/32" x 4-11/23")	60 x 80 ~ 86 mm (2-3/8" x 3-5/32 ~ 3-3/8")	8 mm (5/16")
100 x 115 mm (4" x 4-1/2")	70 x 85 mm (2-5/8" ~ 3" x 3" ~ 3-5/8")	9.5 mm (3/8")


			固定 Fixed	活動 Swivel	煞車 Brake
50mm x 20mm (41.5) (2" x 3/4")	70 kgs (154 lbs)	ZQPU輪(雙輪) ZQPU(Dual Wheels)	—	1165-02-101-2(3)	—	滾珠軸承 Ball Bearing	87mm (3-3/8")	活動 65 mm Swivel 65 mm
50mm x 20mm (41.5) (2" x 3/4")	70 kgs (154 lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-02-101-2(3)	—
50mm x 45mm (2" x 1-13/16")	70 kgs (154 lbs)	QPU輪 QPU	—	1165-02-53-2(3)	—
62.5mm x 20mm (41.5) (2-1/2" x 3/4")	200 kgs (440 lbs)	ZQPU輪(雙輪) ZQPU(Dual Wheels)	—	1165-25-101-2(3)	—	滾珠軸承 Ball Bearing	87mm (3-3/8")	活動 65 mm Swivel 65 mm
62.5mm x 20mm (41.5) (2-1/2" x 3/4")	150 kgs (330 lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-25-101-2(3)	—
62.5mm x 45mm (2-1/2" x 1-13/16")	200 kgs (440 lbs)	QPU輪 QPU	—	1165-25-53-2(3)	—
62.5mm x 20mm (41.5) (2-1/2" x 3/4")	200 kgs (440 lbs)	ZQPU輪(雙輪) ZQPU(Dual Wheels)	—	1165-25-101-2(3)	—	滾珠軸承 Ball Bearing	94mm (3-3/4")	活動 62 mm Swivel 62 mm
62.5mm x 20mm (41.5) (2-1/2" x 3/4")	150 kgs (330 lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-25-101-2(3)	—
62.5mm x 45mm (2-1/2" x 1-13/16")	200 kgs (440 lbs)	QPU輪 QPU	—	1165-25-53-2(3)	—
75mm x 20mm (41.5) (3" x 3/4")	200kgs (440 lbs)	ZQPU輪(雙輪) ZQPU(Dual Wheels)	—	1165-03-101-2(3)	—	滾珠軸承 Ball Bearing	102.5mm (4")	活動 65 mm Swivel 65 mm
75mm x 20mm (41.5) (3" x 3/4")	150 kgs (330 lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-03-101-2(3)	—
75mm x 45mm (3" x 1-13/16")	200 kgs (440 lbs)	QPU輪 QPU	—	1165-03-53-2(3)	—
75mm x 32mm (3" x 1-1/4")	150 kgs (330 lbs)	鋁芯AQPU QPU on AL Core	—	1165-03-87-2(3)	—
75mm x 20mm (41.5) (3" x 3/4")	200kgs (440 lbs)	ZQPU輪(雙輪) ZQPU(Dual Wheels)	—	1165-03-101-2(3)	—	滾珠軸承 Ball Bearing	105.5mm (4-1/8")	活動 72.5 mm Swivel 72.5 mm
75mm x 20mm (41.5) (3" x 3/4")	250 kgs (551 lbs)	ZQPU輪(抗靜電) QPU(Dual Anti-Static Wheels)	—	1165-03-101-2(3)	—
75mm x 45mm (3" x 1-13/16")	200 kgs (440 lbs)	QPU輪 QPU	—	1165-03-53-2(3)	—
75mm x 32mm (3" x 1-1/4")	150 kgs (330 lbs)	鋁芯AQPU QPU on AL Core	—	1165-03-87-2(3)	—
100mm x 32mm (4" x 1-1/4")	200kgs (440 lbs)	鋁芯AQPU QPU on AL Core	—	1165-04-87-2(3)	—	滾珠軸承 Ball Bearing	130mm (5-1/8")	活動 86 mm Swivel 86 mm
100mm x 32mm (4" x 1-1/4")	80 kgs (176 lbs)	W全效輪 W Resolute	—	1165-04-48-2(3)	—
100mm x 34mm (4" x 1-1/2")	110 kgs (242 lbs)	藍色彈力全效輪 Blue Resilient Resolute Rubber	—	1165-04-50-2(3)	—
125mm x 32mm (5" x 1-1/4")	200kgs (440 lbs)	鋁芯AQPU QPU on AL Core	—	1165-05-87-2(3)	—	滾珠軸承 Ball Bearing	158mm (6-1/4")	活動 99 mm Swivel 99 mm
125mm x 32mm (5" x 1-1/4")	100 kgs (220 lbs)	W全效輪 W Resolute	—	1165-05-48-2(3)	—
125mm x 36mm (5" x 1-1/2")	130 kgs (287 lbs)	藍色彈力全效輪 Blue Resilient Resolute Rubber	—	1165-05-50-2(3)	—
