曲軸平衡腳輪系列

Eccentric Caster

得貹曲軸平衡腳輪是一款高性能腳輪，能夠減少推車或拉車時所需的推力，並大幅降低轉向腳輪鎖死發生的機會。得貹曲軸平衡腳架轉向結構提供了二處定位點，更有效的減低台車在移動時的啟動力。所以在有效降低被鎖死的問題和減低啟動力下，得貹曲軸平衡腳輪更適用於 AMR/AGV 行業或是其它需要高荷重但也需求輕鬆推動的手推車與設備上面。

Der Sheng's Eccentric Caster is a highly engineered caster designed to reduce the force needed to push or pull carts. The swivel caster design features with two precision machined offsetting ball races in a compact assembly to minimize the caster lock up issue happened from time to time. A typical swivel assembly in a caster has only one pivot point. The Der Sheng's Eccentric caster essentially provides a second pivot point that reduces the startup force to get the cart moving when lock up in present. By minimizing the lock up issue and reducing the startup force. Der Sheng's Eccentric Caster is especially fit for application like AMR/AGV and Cart/Equipments carrying extra heavy load while requiring effortless maneuverability.

輪子可附金屬防塵蓋(供選擇)
Metal Thread
Guard (optional)

輪子可附塑膠防塵蓋(供選擇)
lastic Thread Guard (optional)

BCD煞(中煞)
Swivel W/Center Lock Brake

PU輪面可以變化硬度
Different PU
Tread hardness available

鐵芯聚氨酯
Pu on Cast

APU輪
APU

鐵芯NBR橡膠輪
NBR Rubber on Cast

尼龍輪
Nylon

WMRC輪
WMRC

QPU輪
QPU

ZQPU輪(雙輪)
ZQPU
(Daul Wheels)

環保NBR橡膠輪
Non-marking Rubber on Cast

鐵芯聚氨酯(2050A/2050B)
PU on Cast(2050A/2050B)

EQPU輪
EQPU

VPU輪
VPU

EPU輪
EPU

VQPU輪
VQPU

鐵芯VXPU
XPU on Iron Core

鋁芯QQ橡膠輪
Recilent rubber on AL Core

環保牽引NBR
Non - marking NBR Rubber
on Cast

鋁芯AQPU
QPU on AL Core

編號 Suffix	底板尺寸 Top Plate Size	底板孔距 Bolt Hole Spacing	安裝尼帽尺寸 Attaching Bolt Size
4"	90 x 120mm (3-17/32" x 4-23/32")	60 x 90mm (2-3/8" x 3-17/32")	11 mm (7/16")
5" 6" 8"	110 x 140mm (4-11/32" x 5-1/2")	75 x 110 mm(常規標準底板) (2-15/16" x 4-11/32")	12 mm (1/2")


			固定 Fixed	活動 Swivel	煞車 Brake
100mm x 32mm (4"x1-1/4")	250 kgs (550 lbs)	尼龍輪 Nylon	1163-04-07-1	1163-04-07-2	1163-04-07-4	滾珠軸承 Ball Bearing	147mm (5-25/32")	活動 116mm BCD煞 116mm Swivel 116mm Swivel W/Center Lock Brake 116mm
100mm x 34mm (4"x1-3/8")	335 kgs (735 lbs)	QPU輪(圓弧) QPU (Round)	1163-04-80-1	1163-04-80-2	1163-04-80-4
100mm x 34mm (4"x1-3/8")	385 kgs (845 lbs)	QPU輪(平面) QPU (Flat)	1163-04-80-1	1163-04-80-2	1163-04-80-4
100mm x 36mm (4"x1-7/16")	250 kgs (550 lbs)	鐵芯聚氨脂 PU on Cast	1163-04-33-1	1163-04-33-2	1163-04-33-4
	250 kgs (550 lbs)	APU輪(圓弧) PU on AL Core (Round)	1163-04-108-1	1163-04-108-2	1163-04-108-4
	300 kgs (660 lbs)	鋁芯AQPU輪(圓弧) QPU on AL Core (Round)	1163-04-87-1	1163-04-87-2	1163-04-87-4
100mm x 38mm (4"x1-1/2")	200 kgs (440 lbs)	鐵芯NBR橡膠輪 NBR Rubber on Cast	1163-04-04-1	1163-04-04-2	1163-04-04-4
	200 kgs (440 lbs)	環保NBR橡膠輪 Non-marking Rubber on Cast	1163-04-11-1	1163-04-11-2	1163-04-11-4
	200 kgs (440 lbs)	環保牽引NBR輪 Non-marking NBR Rubber on Cast	1163-04-90-1	1163-04-90-2	1163-04-90-4
100mm x 40mm (4"x1-9/16")	275 kgs (600 lbs)	APU輪(圓弧) PU on AL Core (Round)	1163-04-108-1	1163-04-108-2	1163-04-108-4
	200 kgs (440 lbs)	鋁芯QQ橡膠輪 Recilent rubber on AL Core	1163-04-89-1	1163-04-89-2	1163-04-89-4
	325 kgs (715 lbs)	鋁芯AQPU輪(圓弧) QPU on AL Core (Round)	1163-04-87-1	1163-04-87-2	1163-04-87-4
100mm x 46.5mm (4"x1-13/16")	335 kgs (735 lbs)	ZQPU輪(雙輪) ZQPU (Dual Wheels)	1163-04-101-1	1163-04-101-2	1163-04-101-4
125mm x 40mm (5"x1-9/16")	340 kgs (750 lbs)	鐵芯聚氨脂 PU on Cast	1163-05-33-1	1163-05-33-2	1163-05-33-4	滾珠軸承 Ball Bearing	170mm (6-11/16")	活動 128.5mm BCD煞 128.5mm Swivel 128.5mm Swivel W/Center Lock Brake 128.5mm
	300 kgs (660 lbs)	尼龍輪 Nylon	1163-05-07-1	1163-05-07-2	1163-05-07-4
	300 kgs (660 lbs)	APU輪(圓弧) PU on AL Core (Round)	1163-05-108-1	1163-05-108-2	1163-05-108-4
	350 kgs (770 lbs)	鋁芯AQPU輪(圓弧) QPU on AL Core (Round)	1163-05-87-1	1163-05-87-2	1163-05-87-4
	250 kgs (550 lbs)	鐵芯NBR橡膠輪 NBR Rubber on Cast	1163-05-04-1	1163-05-04-2	1163-05-04-4
	250 kgs (550 lbs)	環保NBR橡膠輪 Non-marking Rubber on Cast	1163-05-11-1	1163-05-11-2	1163-05-11-4
	250 kgs (550 lbs)	環保牽引NBR輪 Non-marking NBR Rubber on Cast	1163-05-90-1	1163-05-90-2	1163-05-90-4
	450 kgs (990 lbs)	QPU輪(圓弧) QPU (Round)	1163-05-80-1	1163-05-80-2	1163-05-80-4
	500 kgs (1100 lbs)	QPU輪(平面) QPU (Flat)	1163-05-80-1	1163-05-80-2	1163-05-80-4
	340 kgs (750 lbs)	EPU輪(圓弧) EPU (Round Shape)	1163-05-78-1	1163-05-78-2	1163-05-78-4
	390 kgs (860 lbs)	EPU輪(平面) EPU (Flat Shape)	1163-05-78-1	1163-05-78-2	1163-05-78-4
	450 kgs (990 lbs)	EQPU輪(圓弧) EQPU (Round Shape)	1163-05-81-1	1163-05-81-2	1163-05-81-4
	500 kgs (1100 lbs)	EQPU輪(平面) EQPU (Flat Shape)	1163-05-81-1	1163-05-81-2	1163-05-81-4


			固定 Fixed	活動 Swivel	煞車 Brake
125mm x 50mm (5" x 2")	400 kgs (880 lbs)	APU輪(平面) PU on AL Core (Flat)	1163-05-108-1	1163-05-108-2	1163-05-108-4	滾珠軸承 Ball Bearing	170mm (6-11/16")	活動 128.5mm BCD煞 128.5mm Swivel 128.5mm Swivel W/Center Lock Brake 128.5mm
	450 kgs (990 lbs)	鋁芯AQPU輪(平面) QPU on AL Core (Flat)	1163-05-87-1	1163-05-87-2	1163-05-87-4
	420 kgs (920 lbs)	QPU輪(平面) QPU (Flat)	1163-05-80-1	1163-05-80-2	1163-05-80-4
	500 kgs (1100 lbs)	EQPU輪(圓弧) EQPU (Round)	1163-05-81-1	1163-05-81-2	1163-05-81-4
	500 kgs (1100 lbs)	EPU輪(圓弧) EPU (Round)	1163-05-78-1	1163-05-78-2	1163-05-78-4
125mm x 51mm (5" x 2")	450 kgs (990 lbs)	ZQPU輪(雙輪) ZQPU (Dual Wheels)	1163-05-101-1	1163-05-101-2	1163-05-101-4
150mm x 40mm (6"x1-9/16")	400 kgs (880 lbs)	尼龍輪 Nylon	1163-06-07-1	1163-06-07-2	1163-06-07-4	滾珠軸承 Ball Bearing	197mm (7-3/4")	活動 153.5mm BCD煞 153.5mm Swivel 153.5mm Swivel W/Center Lock Brake 153.5mm
	350 kgs (770 lbs)	鐵芯NBR橡膠輪 NBR Rubber on Cast	1163-06-04-1	1163-06-04-2	1163-06-04-4
	300 kgs (660 lbs)	環保NBR橡膠輪 Non-marking Rubber on Cast	1163-06-11-1	1163-06-11-2	1163-06-11-4
	300 kgs (660 lbs)	環保牽引NBR輪 Non-marking NBR Rubber on Cast	1163-06-90-1	1163-06-90-2	1163-06-90-4
	400 kgs (880 lbs)	WMRC輪 WMRC	1163-06-45-1	1163-06-45-2	1163-06-45-4
150mm x 42mm (6"x1-5/8")	410 kgs (900 lbs)	鐵芯聚氨脂 PU on Cast	1163-06-33-1	1163-06-33-2	1163-06-33-4
	400 kgs (880 lbs)	APU輪(圓弧) PU on AL Core (Round)	1163-06-108-1	1163-06-108-2	1163-06-108-4
	450 kgs (990 lbs)	鋁芯AQPU輪(圓弧) QPU on AL Core (Round)	1163-06-87-1	1163-06-87-2	1163-06-87-4
	550 kgs (1200 lbs)	QPU輪(圓弧) QPU (Round)	1163-06-80-1	1163-06-80-2	1163-06-80-4
	600 kgs (1320 lbs)	QPU輪(平面) QPU(Flat)	1163-06-80-1	1163-06-80-2	1163-06-80-4
	500 kgs (1100 lbs)	VPU輪(圓弧) VPU (Round)	1163-06-82-1	1163-06-82-2	1163-06-82-4
	670 kgs (1475 lbs)	VQPU輪(圓弧) VQPU (Round Shape)	1163-06-83-1	1163-06-83-2	1163-06-83-4
	800 kgs (1760 lbs)	鐵芯VXPU輪(圓弧) XPU on Iron Core (Round)	1163-06-91-1	1163-06-91-2	1163-06-91-4
	410 kgs (900 lbs)	EPU輪(圓弧) EPU (Round)	1163-06-78-1	1163-06-78-2	1163-06-78-4
	460 kgs (1010 lbs)	EPU輪(平面) EPU (Flat)	1163-06-78-1	1163-06-78-2	1163-06-78-4
	550 kgs (1200 lbs)	EQPU輪(圓弧) EQPU (Round)	1163-06-81-1	1163-06-81-2	1163-06-81-4
	600 kgs (1320 lbs)	EQPU輪(平面) EQPU (Flat)	1163-06-81-1	1163-06-81-2	1163-06-81-4
150mm x 50mm (6" x 2")	450 kgs (990 lbs)	APU輪(平面) PU on AL Core (Flat)	1163-06(50)-108-1	1163-06(50)-108-2	1163-06(50)-108-4
	500 kgs (1100 lbs)	鋁芯AQPU輪(平面) QPU on AL Core (Flat)	1163-06(50)-87-1	1163-06(50)-87-2	1163-06(50)-87-4
	525 kgs (1155 lbs)	QPU輪(平面) QPU(Flat)	1163-06(50)-80-1	1163-06(50)-80-2	1163-06(50)-80-4
	600 kgs (1320 lbs)	EPU輪(圓弧) EPU (Round)	1163-06(50)-78-1	1163-06(50)-78-2	1163-06(50)-78-4
	600 kgs (1320 lbs)	EQPU輪(圓弧) EQPU (Round)	1163-06(50)-81-1	1163-06(50)-81-2	1163-06(50)-81-4
150mm x 51mm (6" x 2")	550 kgs (1210 lbs)	ZQPU輪(雙輪) ZQPU (Dual Wheels)	1163-06-101-1	1163-06-101-2	1163-06-101-4
180mm x 44mm (7" x 1-3/4")	450 kgs (990 lbs)	APU輪(圓弧) PU on AL Core (Round)	1163-07-108-1	1163-07-108-2	1163-07-108-4	滾珠軸承 Ball Bearing	238mm (9-3/8")	活動 181.5mm BCD煞 181.5mm Swivel 181.5mm Swivel W/Center Lock Brake 181.5mm
180mm x 44mm (7" x 1-3/4")	600 kgs (1320 lbs)	鋁芯AQPU輪(圓弧) QPU on AL Core (Round)	1163-07-87-1	1163-07-87-2	1163-07-87-4	滾珠軸承 Ball Bearing	238mm (9-3/8")


			固定 Fixed	活動 Swivel	煞車 Brake
180mm x 50mm (7" x 2")	450 kgs (990 lbs)	鐵芯聚氨脂 PU on Cast	1163-07-33-1	1163-07-33-2	1163-07-33-4	滾珠軸承 Ball Bearing	238mm (9-3/8")	活動 181.5mm BCD煞 181.5mm Swivel 181.5mm Swivel W/Center Lock Brake 181.5mm
	600 kgs (1320 lbs)	QPU輪(圓弧) QPU(Round)	1163-07-80-1	1163-07-80-2	1163-07-80-4
	650 kgs (1430 lbs)	VPU輪(圓弧) VPU (Round)	1163-07-82-1	1163-07-82-2	1163-07-82-4
	650 kgs (1430 lbs)	鐵芯VXPU輪(圓弧) XPU on Iron Core (Round)	1163-07-91-1	1163-07-91-2	1163-07-91-4
	650 kgs (1430 lbs)	VQPU輪(圓弧) VQPU (Round Shape)	1163-07-83-1	1163-07-83-2	1163-07-83-4
200mm x 44mm (8"x1-3/4")	350 kgs (770 lbs)	鐵芯NBR橡膠輪 NBR Rubber on Cast	1163-08-04-1	1163-08-04-2	1163-08-04-4	滾珠軸承 Ball Bearing	248mm (9-3/4")	活動 191.5mm BCD煞 191.5mm Swivel 191.5mm Swivel W/Center Lock Brake 191.5mm
	350 kgs (770 lbs)	環保NBR橡膠輪 Non-marking Rubber on Cast	1163-08-11-1	1163-08-11-2	1163-08-11-4
	350 kgs (770 lbs)	環保牽引NBR輪 Non-marking NBR Rubber on Cast	1163-08-90-1	1163-08-90-2	1163-08-90-4
	400 kgs (880 lbs)	鋁芯QQ橡膠輪 Recilent rubber on AL Core	1163-08-89-1	1163-08-89-2	1163-08-89-4
200mm x 50mm (8" x 2")	450 kgs (990 lbs)	鐵芯聚氨脂 PU on Cast	1163-08-33-1	1163-08-33-2	1163-08-33-4	滾珠軸承 Ball Bearing	248mm (9-3/4")	活動 191.5mm BCD煞 191.5mm Swivel 191.5mm Swivel W/Center Lock Brake 191.5mm
	450 kgs (990 lbs)	尼龍輪 Nylon	1163-08-07-1	1163-08-07-2	1163-08-07-4
	750 kgs (1650 lbs)	鐵芯聚氨脂(2050A/2050B) PU on Cast (2050A/2050B)	1163-08-62-1	1163-08-62-2	1163-08-62-4
	450 kgs (990 lbs)	WMRC輪 WMRC	1163-08-45-1	1163-08-45-2	1163-08-45-4
	500 kgs (1100 lbs)	APU輪(圓弧) PU on AL Core (Round)	1163-08-108-1	1163-08-108-2	1163-08-108-4
	550 kgs (1200 lbs)	APU輪(平面) PU on AL Core (Flat)	1163-08-108-1	1163-08-108-2	1163-08-108-4
	650 kgs (1430 lbs)	鋁芯AQPU輪(圓弧) QPU on AL Core (Round)	1163-08-87-1	1163-08-87-2	1163-08-87-4
	700 kgs (1540 lbs)	鋁芯AQPU輪(平面) QPU on AL Core (Flat)	1163-08-87-1	1163-08-87-2	1163-08-87-4
	670 kgs (1475 lbs)	QPU輪(圓弧) QPU (Round)	1163-08-80-1	1163-08-80-2	1163-08-80-4
	720 kgs (1580 lbs)	QPU輪(平面) QPU (Flat)	1163-08-80-1	1163-08-80-2	1163-08-80-4
	670 kgs (1475 lbs)	VPU輪(圓弧) VPU (Round)	1163-08-82-1	1163-08-82-2	1163-08-82-4
	800 kgs (1760 lbs)	VQPU輪(圓弧) VQPU (Round)	1163-08-83-1	1163-08-83-2	1163-08-83-4
	1100 kgs (2420 lbs)	鐵芯VXPU輪(圓弧) XPU on Iron Core (Round)	1163-08-91-1	1163-08-91-2	1163-08-91-4
	650 kgs (1430 lbs)	EPU輪(圓弧) EPU (Round Shape)	1163-08-78-1	1163-08-78-2	1163-08-78-4
	700 kgs (1540 lbs)	EPU輪(平面) EPU (Flat Shape)	1163-08-78-1	1163-08-78-2	1163-08-78-4
	750 kgs (1650 lbs)	EQPU輪(圓弧) EQPU (Round Shape)	1163-08-81-1	1163-08-81-2	1163-08-81-4
	800 kgs (1760 lbs)	EQPU輪(平面) EQPU (Flat Shape)	1163-08-81-1	1163-08-81-2	1163-08-81-4
200mm x 51mm (8" x 2")	650 kgs (1430 lbs)	ZQPU輪(雙輪) ZQPU (Dual Wheels)	1163-08-101-1	1163-08-101-2	1163-08-101-4
