抗衝擊彈簧系列

Kingpinless Spring-loaded Caster

屬得貹專利產品，避震，超重負載且高抗衝擊，在搬運過程可避免腳架形扭曲，多款供選擇。採用超厚板材及高級彈簧，品質、工藝明顯優於市場上同類產品。

DERSHENG'S patented prouducts, shock-absorbing, heavy duty Kingpinless castera with hardened raceways for greater impact resistance to avoid distortions under heavy load. Made of super thick steel and high quality spring, outperforming most products from competitors.

無鉚釘設計
Kingpinless

AK煞
Swivel W/Center Lock(AK type)
&輪子可附塑膠防塵蓋(供選擇)
Plastic Thread Guard(optional)

PU輪面可以變化硬度
Different PU tread
handness available

鐵芯聚氨酯
PU on Cast

QPU輪
QPU

鋁芯AQPU
QPU on AL Core

環保牽引NBR
Non - marking NBR Rubber on Cast

鐵芯NBR橡膠輪(叉車料)
NBR Rubber on Cast

EPU輪
EPU

EQPU輪
EQPU

VPU輪
VPU

VQPU輪
VQPU

尼龍輪
Nylon

WMRC輪
WMRC

腳輪尺寸 Caster Size	底板尺寸 Top Plate Size	底板孔距 Bolt Hole Spacing	安裝尼帽尺寸 Attching Bolt Size
1	110 x 140mm (4-11/32" x 5-1/2")	75 x 110mm(常規標準底板) (2-15/16" x 4-11/32")	12 mm (1/2")
	110 x 140mm (4-11/32" x 5-1/2")	80 x 105mm(歐規孔距) (3-5/32" x 4-1/8"(European Plate))	12 mm (1/2")
	130 x 165mm (5-1/8" x 6-1/2")	100 x 130mm (3-15/16" x 5-1/8")	12 mm (1/2")
	114 x 159mm (4-1/2" x 6-1/4")	73.8 x 129.4mm (2-29/32" x 5-3/32")	12 mm (1/2")


			活動 Swivel	固定 Fixed	剎車 Brake
125mm x 40mm (5" x 1-9/16")	200 kgs (440 lbs)	尼龍輪 Nylon	1145-05-07-1	1145-05-07-2	1145-05-07-4	滾珠 Ball Bearing	210mm (8-9/32")	活動 132mm AK煞 194mm Swivel 132mm Swivel W/AK lock brake 194mm
	200 kgs (440 lbs)	環保牽引NBR輪 Non-marking NBR Rubber on Cast	1145-05-90-1	1145-05-90-2	1145-05-90-4
	250 kgs (550 lbs)	鋁芯AQPU QPU on AL Core	1145-05-87-1	1145-05-87-2	1145-05-87-4
	200 kgs (440 lbs)	鐵芯聚氨脂 PU on Cast	1145-05-33-1	1145-05-33-2	1145-05-33-4
	200 kgs (440 lbs)	鐵芯NBR橡膠輪 NBR Rubber on Cast	1145-05-04-1	1145-05-04-2	1145-05-04-4
	250 kgs (550 lbs)	QPU輪 QPU	1145-05-80-1	1145-05-80-2	1145-05-80-4
	250 kgs (550 lbs)	EPU輪 EPU	1145-05-78-1	1145-05-78-2	1145-05-78-4
	350 kgs (770 lbs)	EQPU輪 EQPU	1145-05-81-1	1145-05-81-2	1145-05-81-4
150mm x 40mm (6" x 1-9/16")	250 kgs (550 lbs)	鐵芯NBR橡膠輪 NBR Rubber on Cast	1145-06-04-1	1145-06-04-2	1145-06-04-4	滾珠 Ball Bearing	225mm (8-27/32")	活動 146mm AK煞 200mm Swivel 146mm Swivel W/AK lock brake 200mm
	250 kgs (550 lbs)	尼龍輪 Nylon	1145-06-07-1	1145-06-07-2	1145-06-07-4
	250 kgs (550 lbs)	環保牽引NBR輪 Non-marking NBR Rubber on Cast	1145-06-90-1	1145-06-90-2	1145-06-90-4
	250 kgs (550 lbs)	WMRC輪 WMRC	1145-06-45-1	1145-06-45-2	1145-06-45-4
150mm x 42mm (6" x 1-5/8")	250 kgs (550 lbs)	鐵芯聚氨脂 PU on Cast	1145-06-33-1	1145-06-33-2	1145-06-33-4
	300 kgs (660 lbs)	鋁芯AQPU QPU on AL Core	1145-06-87-1	1145-06-87-2	1145-06-87-4
	300 kgs (660 lbs)	QPU輪 QPU	1145-06-80-1	1145-06-80-2	1145-06-80-4
	300 kgs (660 lbs)	EPU輪 EPU	1145-06-78-1	1145-06-78-2	1145-06-78-4
	400 kgs (880 lbs)	EQPU輪 EQPU	1145-06-81-1	1145-06-81-2	1145-06-81-4
	400 kgs (880 lbs)	VPU輪 VPU	1145-06-82-1	1145-06-82-2	1145-06-82-4
	500 kgs (1100 lbs)	VQPU輪 VQPU	1145-06-83-1	1145-06-83-2	1145-06-83-4
150mm x 46mm (6" x 1-13/16")	300 kgs (660 lbs)	鐵芯NBR橡膠輪 NBR Rubber on Cast	1145-06-04-1	1145-06-04-2	1145-06-04-4
200mm x 44mm (8" x 1-3/4")	300 kgs (660 lbs)	鐵芯NBR橡膠輪 NBR Rubber on Cast	1145-08-04-1	1145-08-04-2	1145-08-04-4	滾珠 Ball Bearing	280mm (11-1/32")	活動 182mm AK煞 254mm Swivel 182mm Swivel W/AK lock brake 254mm
200mm x 44mm (8" x 1-3/4")	300 kgs (660 lbs)	環保牽引NBR輪 Non-marking NBR Rubber on Cast	1145-08-90-1	1145-08-90-2	1145-08-90-4
200mm x 50mm (8" x 2")	300 kgs (660 lbs)	鐵芯聚氨脂 PU on Cast	1145-08-33-1	1145-08-33-2	1145-08-33-4
	350 kgs (770 lbs)	QPU輪 QPU	1145-08-80-1	1145-08-80-2	1145-08-80-4
	350 kgs (770 lbs)	EPU輪 EPU	1145-08-78-1	1145-08-78-2	1145-08-78-4
	450 kgs (990 lbs)	EQPU輪 EQPU	1145-08-81-1	1145-08-81-2	1145-08-81-4
	450 kgs (990 lbs)	VPU輪 VPU	1145-08-82-1	1145-08-82-2	1145-08-82-4
	550 kgs (1210 lbs)	VQPU輪 VQPU	1145-08-83-1	1145-08-83-2	1145-08-83-4
	300 kgs (660 lbs)	尼龍輪 Nylon	1145-08-07-1	1145-08-07-2	1145-08-07-4
	300 kgs (660 lbs)	WMRC輪 WMRC	1145-08-45-1	1145-08-45-2	1145-08-45-4
	350 kgs (770 lbs)	鋁芯AQPU QPU on AL Core	1145-08-87-1	1145-08-87-2	1145-08-87-4
