DF型系列
1-1/2" Wide General Purposes Caster (American Style)
高負載且轉動靈活，普遍適用於一般工廠搬運，另可附防纏絲及防塵蓋，屬得貹專利產品，可以有效防止腳輪因灰塵或纏絲而無法轉動，提高腳輪使用壽命。
工業腳輪,搬運台車,車輪,腳輪
Swivel easily under heavy load, for workshop carts. Patented thread guards prevent swivel failute caused by build-up of strings between the wheel and fork legs, as well as the dust in the wheel bearing.
鐵芯NBR橡膠輪
NBR Rubber
on Cast		 鐵芯聚氨酯
PU on Cast		 三星輪
Rubber on Cast		 環保NBR橡膠輪
Non-marking
Rubber on Cast		 W全校輪
W Resolute		 WCPD輪
WCPD		 QPU輪
QPU
尼龍輪
Nylon		 銑輪
Cast Iron		 CPD輪
CPD		 風硬全效輪
Resolute		 WMRC輪
WMRC		 EPU輪
EPU		 EQPU輪
EQPU
鋁芯AQPU
QPU on
AL Core		 金剛輪
King Kong Wheel
編號
Suffix		 底板尺寸
Top Plate Size		 底板孔距
Bolt Hole Spacing		 安裝尼帽尺寸
Attaching Bolt Size
1 100 x 115 mm (4"x 4-1/2") 70 x 85 mm (2-5/8"~3" x 3"~3-5/8") 9.5mm(3/8")
2 108 x 84 mm (4-1/4"x 3-5/16") 87.5 x 63.5 mm (3-7/16 x 2-1/2") M8 (5/16")
3 115 x 159 mm (4-1/2"x 6-1/4") 75 x 130 mm (2-7/16~3-3/8" x 4-15/16"~5-1/4") 12.7mm(1/2")


固定
Fixed		 活動
Swivel		 煞車
Brake
50mm x 45mm
(2" x 1-3/4")		 275 kgs(606 lbs) 金剛輪
King Kong Wheel		 11240200711013 11240200712013 — 滾珠
Ball Bearing		 82mm
(3-1/4")		 活動
51mm (2")
Swivel 51mm (2")
93mm x 28mm
(3-21/32" x 1-3/32")		 175 kgs(385 lbs) 銑輪
Cast Iron		 1124-04-14-1 1124-04-14-2 — 滾珠
Ball Bearing		 138.5mm 活動 71.5mm
Swivel 71.5mm
100mm x 32mm
(4" x 1-1/4")		 200 kgs(440 lbs) 尼龍輪
Nylon		 1124-04-07-1 1124-04-07-2 1124-04-07-4 滾珠
Ball Bearing		 142mm
(5-5/8")		 活動 75mm
側煞 75mm
中煞 115mm

Swivel 75mm

Swivel W/Side
Brake 75mm

Swivel W/Center
lock 115mm
150 kgs(330 lbs) CPD輪
CPD		 1124-04-49-1 1124-04-49-2 1124-04-49-4
100mm x 34mm
(4" x 1-1/3")		 200 kgs(440 lbs) 鐵芯聚氨酯
PU on Cast		 1124-04-33-1 1124-04-33-2 1124-04-33-4
300 kgs(660 lbs) QPU輪
QPU		 1124-04-80-1 1124-04-80-2 1124-04-80-4
150 kgs(330 lbs) 鐵芯NBR橡膠輪
NBR Rubber on Cast		 1124-04-04-1 1124-04-04-2 1124-04-04-4
150 kgs(330 lbs) 環保NBR橡膠輪
Non-marking Rubber on Cast		 1124-04-11-1 1124-04-11-2 1124-04-11-4
100mm x 35mm
(4" x 1-1/8")		 150 kgs(330 lbs) 三星輪
Rubber on Cast		 1124-04-03-1 1124-04-03-2 1124-04-03-4
100mm x 36mm
(4" x 1-7/16")		 325 kgs(715 lbs) 鋁芯AQPU(圓弧)
QPU on AL Core (Round)		 1124-04-87-1 1124-04-87-2 1124-04-87-4
100mm x 37.5mm
(4" x 1-1/2")		 140 kgs(308 lbs) W全效輪
W Resolute		 1124-04-64-1 1124-04-64-2 1124-04-64-4
100mm x 40mm
(4" x 1-9/16")		 350 kgs(770 lbs) 鋁芯AQPU(圓弧)
QPU on AL Core (Round)		 1124-04(40)-87-1 1124-04(40)-87-2 1124-04(40)-87-4
122mm x 36mm
(4-13/16" x 1-7/16")		 250 kgs(550 lbs) 銑輪
Cast Iron		 1124-05-14-1 1124-05-14-2 — 滾珠
Ball Bearing		 165.5mm 活動 91.5mm
Swivel 91.5mm
125mm x 37.5mm
(5" x 1-1/2")		 250 kgs(550 lbs) W全效輪
W Resolute		 1124-05-64-1 1124-05-64-2 1124-05-64-4 滾珠
Ball Bearing		 167mm
(6-1/2")		 活動 93mm
側煞 93mm
中煞 112mm

Swivel 93mm

Swivel W/Side
Brake 93mm

Swivel W/Center
lock 112mm
125mm x 40mm
(5" x 1-9/16")		 250 kgs(550 lbs) 鐵芯聚氨酯
PU on Cast		 1124-05-33-1 1124-05-33-2 1124-05-33-4
350 kgs(770 lbs) QPU輪
QPU		 1124-05-80-1 1124-05-80-2 1124-05-80-4
350 kgs(770 lbs) 鋁芯AQPU(圓弧)
QPU on AL Core (Round)		 1124-05-87-1 1124-05-87-2 1124-05-87-4
250 kgs(550 lbs) EPU輪
EPU		 1124-05-78-1 1124-05-78-2 1124-05-78-4
300 kgs(660 lbs) EQPU輪
EQPU		 1124-05-81-1 1124-05-81-2 1124-05-81-4
200 kgs(440 lbs) 三星輪
Rubber on Cast 		1124-05-03-1 1124-05-03-2 1124-05-03-4
200 kgs(440 lbs) 鐵芯NBR橡膠輪
NBR Rubber on Cast		 1124-05-04-1 1124-05-04-2 1124-05-04-4
200 kgs(440 lbs) 環保NBR橡膠輪
Non-marking Rubber on Cast		 1124-05-11-1 1124-05-11-2 1124-05-11-4
125mm x 41mm
(5" x 1-5/8")		 250 kgs(550 lbs) 尼龍輪
Nylon		 1124-05-07-1 1124-05-07-2 1124-05-07-4
200 kgs(440 lbs) CPD輪
CPD		 1124-05-49-1 1124-05-49-2 1124-05-49-4
138mm x 42mm
(5-7/16" x 1-5/8")		 300 kgs(660 lbs) 銑輪
Cast Iron		 1124-06-14-1 1124-06-14-2 — 滾珠
Ball Bearing		 184mm 活動 104mm
Swivel 104mm
150mm x 37.5mm
(6" x 1-1/2")		 180 kgs(396 lbs) W全效輪
W Resolute		 1124-06-64-1 1124-06-64-2 1124-06-64-4 滾珠
Ball Bearing		 190mm
(7-1/2")		 活動 110mm
側煞 110mm
中煞 160mm

Swivel 110mm

Swivel W/Side
Brake 110mm

Swivel W/Center
lock 160mm
150mm x 40mm
(6" x 1-9/16")		 250 kgs(550 lbs) 鐵芯NBR橡膠輪
NBR Rubber on Cast		 1124-06-04-1 1124-06-04-2 1124-06-04-4
250 kgs(550 lbs) 環保NBR橡膠輪
Non-marking Rubber on Cast		 1124-06-11-1 1124-06-11-2 1124-06-11-4
350 kgs(770 lbs) 尼龍輪
Nylon		 1124-06-07-1 1124-06-07-2 1124-06-07-4
250 kgs(550 lbs) CPD輪
CPD		 1124-06-49-1 1124-06-49-2 1124-06-49-4
350 kgs(770 lbs) WMRC輪
WMRC		 1124-06-45-1 1124-06-45-2 1124-06-45-4
250 kgs(550 lbs) WCPD輪
WCPD		 1124-06-79-1 1124-06-79-2 1124-06-79-4
* 50mm x 45mm (2" x 1-3/4") Static load capacity:550kg (1212.5 lbs)


固定
Fixed		 活動
Swivel		 煞車
Brake
150mm x 42mm
(6" x 1-5/8")		 350 kgs(770 lbs) 鐵芯聚氨酯
PU on Cast		 1124-06-33-1 1124-06-33-2 1124-06-33-4 滾珠
Ball Bearing		 190mm
(7-1/2")		 活動 110mm
側煞 110mm
中煞 160mm

Swivel 110mm

Swivel W/Side
Brake 110mm

Swivel W/Center
lock 160mm
400 kgs(880 lbs) QPU輪
QPU		 1124-06-80-1 1124-06-80-2 1124-06-80-4
350 kgs(770 lbs) EPU輪
EPU		 1124-06-78-1 1124-06-78-2 1124-06-78-4
400 kgs(880 lbs) EQPU輪
EQPU		 1124-06-81-1 1124-06-81-2 1124-06-81-4
400 kgs(880 lbs) 鋁芯AQPU(圓弧)
QPU on AL Core (Round)		 1124-06-87-1 1124-06-87-2 1124-06-87-4
150mm x 45.5mm
(6" x 1-13/16")		 220 kgs(485 lbs) 三星輪
Rubber on Cast		 1124-06-03-1 1124-06-03-2 1124-06-03-4
200mm x 44mm
(8" x 1-3/4")		 300 kgs(660 lbs) 鐵芯NBR橡膠輪
NBR Rubber on Cast		 1124-08-04-1 1124-08-04-2 1124-08-04-4 滾珠
Ball Bearing		 240mm
(9-1/2")		 活動 145mm
側煞 145mm
中煞 162.5mm

Swivel 145mm

Swivel W/Side
Brake 145mm

Swivel W/Center
lock 162.5mm
300 kgs(660 lbs) 環保NBR橡膠輪
Non-marking Rubber on Cast		 1124-08-11-1 1124-08-11-2 1124-08-11-4
200mm x 45mm
(8" x 1-13/16")		 350 kgs(770 lbs) 銑輪
Cast Iron		 1124-08-14-1 1124-08-14-2 1124-08-14-4
200mm x 50mm
(8" x 2")		 400 kgs(880 lbs) 鐵芯聚氨酯
PU on Cast		 1124-08-33-1 1124-08-33-2 1124-08-33-4
400 kgs(880 lbs) QPU輪
QPU		 1124-08-80-1 1124-08-80-2 1124-08-80-4
400 kgs(880 lbs) EPU輪
EPU		 1124-08-78-1 1124-08-78-2 1124-08-78-4
400 kgs(880 lbs) EQPU輪
EQPU		 1124-08-81-1 1124-08-81-2 1124-08-81-4
260 kgs(570 lbs) 三星輪
Rubber on Cast		 1124-08-03-1 1124-08-03-2 1124-08-03-4
300 kgs(660 lbs) 鐵芯NBR橡膠輪
NBR Rubber on Cast		 1124-08-04-1 1124-08-04-2 1124-08-04-4
300 kgs(660 lbs) 環保NBR橡膠輪
Non-marking Rubber on Cast		 1124-08-11-1 1124-08-11-2 1124-08-11-4
400 kgs(880 lbs) 尼龍輪
Nylon		 1124-08-07-1 1124-08-07-2 1124-08-07-4
300 kgs(660 lbs) CPD輪
CPD		 1124-08-49-1 1124-08-49-2 1124-08-49-4
180 kgs(396 lbs) 風硬全效輪
Resolute		 1124-08-53-1 1124-08-53-2 1124-08-53-4
400 kgs(880 lbs) WMRC輪
WMRC		 1124-08-45-1 1124-08-45-2 1124-08-45-4
300 kgs(660 lbs) WCPD輪
WCPD		 1124-08-79-1 1124-08-79-2 1124-08-79-4
400 kgs(880 lbs) 鋁芯AQPU(圓弧)
QPU on AL Core (Round)		 1124-08-87-1 1124-08-87-2 1124-08-87-4
400 kgs(880 lbs) 鋁芯AQPU(平面)
QPU on AL Core (Flat)		 1124-08-87-1 1124-08-87-2 1124-08-87-4
