高級5x2系列
2" Wide Institutional Caster (American Style Tool Cart Caster)
專門為工具箱用的高荷重輪,外型設計美觀、耐用。
Appealing exterior design with great load capacity to
compliment tool carts both functionally and aesthetically
反珠碗
Extra Clerance Between
Top Plate and Body
前煞(雙踏)
Center Lock Brake
(double pedals)
前煞(單踏)
Center Lock Brake
(single pedal)
側煞
Side Lock Brake
編號
Suffix
底板尺寸
Top Plate Size
底板孔距
Bolt Hole Spacing
安裝尼帽尺寸
Attaching Bolt Size
1 69 x 96 mm (2-23/32" x 3-25/32") 45 x 75 mm (高級架底板)(Plate)
(1-3/4" x 3")
6.35 mm (1/4")
2 105 x 115 mm (4-1/8" x 4-1/2") 70 x 85 mm (大底板)(Big Plate)
(2-5/8"~3" x 3"~3-5/8")
9.5 mm (3/8")


固定
Fixed
活動
Swivel
煞車
Brake
100mm x 48mm
(4" x 1-7/8")
80kgs (176 lbs) 塑料輪
PP
1111-TC-04-29-1 1111-TC-04-29-2 1111-TC-04-29-4 中管
Plain Bearing
高級架底板類總高
(側煞/單踏)
Plate OAH:
138.5mm (5-7/16")

大底板類總高
(側煞/單踏)
Big Plate OAH:
139.5mm (5-1/2")
活動 91mm
側煞 94mm
前煞(單踏) 118.5mm

Swivel 91mm
Swivel W/Side Brake 94mm
Swivel W/Center lock 118.5mm
(single pedal)
100mm x 50mm
(4" x 2")
130kgs (286 lbs) HDR輪
HDR
1111-TC-04-74-1 1111-TC-04-74-2 1111-TC-04-74-4 滾珠
Ball Bearing
125mm x 49mm
(5" x 1-15/16")
100kgs (220 lbs) 塑料輪
PP
1111-TC-05-29-1 1111-TC-05-29-2 1111-TC-05-29-4 中管
Plain Bearing
高級架底板類總高(側煞)
Plate OAH:
158mm (6-1/4")

高級架底板+反珠碗類總高
(單踏/雙踏)
Plate with extra
clerance OAH:
176.5mm (6-15/16")

大底板類總高(單踏/雙踏)
Big Plate OAH:
165mm (6-1/2")
活動 97.5mm
側煞 97.5mm
前煞(單踏) 118.5mm
前煞(雙踏) 132.5mm

Swivel 97.5mm
Swivel W/Side Brake 97.5mm
Swivel W/Center lock 118.5mm
(single pedal)
Swivel W/Center lock 132.5mm
(double pedals
100kgs (220 lbs) 風火輪
Designed PP Wheel
1111-TC-05-65-1 1111-TC-05-65-2 1111-TC-05-65-4 中管
Plain Bearing
100kgs (220 lbs) 塑料輪(三風型)
PP
1111-TC-05-73-1 1111-TC-05-73-2 1111-TC-05-73-4 中管
Plain Bearing
125mm x 50mm
(5" x 2")
90kgs (198 lbs) 超級人造膠
TPR on PP Core
1111-TC-05-26-1 1111-TC-05-26-2 1111-TC-05-26-4 滾珠
Ball Bearing
A珠軸承
Flanged Ball
Bearing
130kgs (286 lbs) HDR輪
HDR
1111-TC-05-74-1 1111-TC-05-74-2 1111-TC-05-74-4 滾珠
Ball Bearing
150mm x 50mm
(6" x 2")
130kgs (286 lbs) 超級人造膠
TPR on PP Core
1111-TC-06-26-1 1111-TC-06-26-2 1111-TC-06-26-4 滾珠
Ball Bearing
高級架底板+反珠碗類總高(雙踏)
Plate with extra clerance
OAH:201mm (7-15/16")

大底板類總高(雙踏)
Big Plate OAH: 187mm (7-3/8")
活動 111.5mm
前煞(雙踏) 132.5mm

Swivel 111.5mm
Swivel W/Center lock 132.5mm
(double pedals)
130kgs (286 lbs) HDR輪
HDR
1111-TC-06-74-1 1111-TC-06-74-2 1111-TC-06-74-4 滾珠
Ball Bearing
