日式輪系列(重型)
Heavy Duty General Purposes Caster (Japanese Style)
轉動靈活寧靜, 腳架已有特殊加強, 強度大幅度提升及抗衝擊, 另有側剎可供選擇
Reinforce fork design to further improve load rating
and impact resistance, Side lock brake is available.
日式腳輪,設備推車,車輪,工業輪
側剎
Side Lock Brake		 波盤防塵蓋
Swivel Dust Cover		 輪子可附金屬防塵蓋
Metal Thread Guard
鐵芯日式橡膠輪
Rubber on Steel Core		 尼龍輪
Nylon		 高科技耐磨聚氨酯(尼龍芯)
PU on PA Core		 W全效輪
W Resolute
鋁芯AQPU
QPU on AL Core		 EQPU輪
EQPU		 鋁芯橡膠輪
Rubber on AL Core		 WMRC輪
WMRC


腳輪尺寸
Caster Size		 底板尺寸
Top Plate Size		 底板孔距
Bolt Hole Spacing		 安裝尼帽尺寸
Attaching Bolt Size
4" 5" 6" 活動底板
4" 5" 6" Swivel plate		 101 x 101mm (4" x 4") 78 x 78mm (3-1/16" x 3-1/16") 10mm (3/8")
腳輪尺寸
Caster Size		 底板尺寸
Top Plate Size		 底板孔距
Bolt Hole Spacing		 安裝尼帽尺寸
Attaching Bolt Size
5" 6" 活動底板
5" 6" Swivel plate		 91 x 140mm (3-9/16" x 5-1/2") 55 x 105mm (2-1/8" x 4-1/8") 10mm (3/8")
固定
Fixed		 活動
Swivel		 煞車
Brake
100mm x 32mm
(4"x1-1/4")		 250 kgs
(550 lbs)		 尼龍輪
Nylon		 — 1108-H-04-07-2 1108-H-04-07-4 滾珠軸承
Ball Bearing		 138mm
(5-7/16")		 活動 87.5mm
Swivel 67mm

側剎87.5mm
Swivel W/Side
brake 87.5mm
100mm x 36mm
(4"x1-7/16")		 270 kgs
(594 lbs)		 鋁芯AQPU(圓弧)
QPU on AL Core (Round)		 — 1108-H-04-87-2 1108-H-04-87-4
140 kgs
(308 lbs)		 W全效輪
W Resolute		 — 1108-H-04-64-2 1108-H-04-64-4
100mm x 40mm
(4"x1-9/16")		 300 kgs
(660 lbs)		 鋁芯AQPU(圓弧)
QPU on AL Core (Round)		 — 1108-H-04-87(40)-2 1108-H-04-87(40)-4
200 kgs
(440 lbs)		 鋁芯橡膠輪
Rubber on AL Core		 — 1108-H-04-22-2 1108-H-04-22-4
125mm x 38mm
(5"x1-1/2")		 160 kgs
(352 lbs)		 W全效輪
W Resolute		 1108-H-05-64-1 1108-H-05-64-2 1108-H-05-64-4 滾珠軸承
Ball Bearing		 168mm
(6-5/8")		 活動98.5mm
Swivel 98.5mm

側剎 98.5mm
Swivel W/Side
brake 98.5mm
125mm x 40mm
(5"x1-9/16")		 300 kgs
(660 lbs)		 尼龍輪
Nylon		 1108-H-05-07-1 1108-H-05-07-2 1108-H-05-07-4
300 kgs
(660 lbs)		 鋁芯AQPU(圓弧)
QPU on AL Core(Round)		 1108-H-05-87-1 1108-H-05-87-2 1108-H-05-87-4
300 kgs
(660 lbs)		 EQPU輪(圓弧)
EQPU(Round)		 1108-H-05-81-1 1108-H-05-81-2 1108-H-05-81-4
250 kgs
(550 lbs)		 鋁芯橡膠輪
Rubber on AL Core		 1108-H-05-22-1 1108-H-05-22-2 1108-H-05-22-4
150mm x 38mm
(6"x1-1/2")		 180kgs
(396 lbs)		 W全效輪
W Resolute		 1108-H-06-64-1 1108-H-06-64-2 1108-H-06-64-4 滾珠軸承
Ball Bearing		 191mm
(7-1/2")		 活動 113mm
Swivel 113mm

側剎 113mm
Swivel W/Side
brake 113mm
150mm x 40mm
(6"x1-9/16")		 160kgs
(352 lbs)		 鐵芯日式橡膠輪
Swivel Dust Cover		 1108-H-06-18-1 1108-H-06-18-2 1108-H-06-18-4
300kgs
(660 lbs)		 WMRC輪
WMRC		 1108-H-06-45-1 1108-H-06-45-2 1108-H-06-45-4
280kgs
(616 lbs)		 鋁芯橡膠輪
Rubber on AL Core		 1108-H-06-22-1 1108-H-06-22-2 1108-H-06-22-4
150mm x 42mm
(6"x1-5/8")		 300kgs
(660 lbs)		 鋁芯AQPU(圓弧)
QPU on AL Core(Round)		 1108-H-06-87-1 1108-H-06-87-2 1108-H-06-87-4
300kgs
(660 lbs)		 EQPU輪(圓弧)
EQPU(Round)		 1108-H-06-81-1 1108-H-06-81-2 1108-H-06-81-4
150mm x 44mm
(6"x1-3/4")		 200kgs
(440 lbs)		 高科技耐磨聚氨酯(尼龍芯)
PU on PA Core		 1108-H-06-34-1 1108-H-06-34-2 1108-H-06-34-4
