藍架系列
Blue Fork Pneumatic Caster

高負載, 適用於水泥路面或凹凸不平的地面,所配風輪、風硬輪, 採用優質橡膠製成,荷重高,耐磨耐衝擊

Heavy-duty, good for cement ground and uneven floor, Wheel options include pueumatic wheels and solid rubber wheels, made of quality rubber to withstand abrasion and impact under heavy load.
  中剎
Center Lock Brake
風輪(烤漆鐵框)
Pneumatic with painted steel rim
風輪(塑框)
Pneumatic with plastic rim
風輪(鍍鋅鐵框)
Pneumatic with plated steel rim
防爆輪
Flat Free Tire
風硬全效輪
Resoulte Rubber
風硬W全效輪
W Resoulte Rubber
風硬輪(鍍鋅鐵框)
Solid Rubber wheel with plated steel rim
風硬輪(烤漆鐵框)
Solid Rubber wheel with painted steel rim


編號
Suffix
底板尺寸
Top Plate Size
底板孔距
Bolt Hole Spacing
安裝尼帽尺寸
Attaching Bolt Size
8"藍架
8"Caster
105 mm x 144 mm (4-1/8" x 5-11/16") 75 mm x 120 mm (3" x 4-3/4")
12 mm (1/2")
8"藍架
8"Caster
130 mm x 167 mm (5-1/8" x 6-11/16") 100 mm x 140 mm (4" x 5-1/2")
12 mm (1/2")
10"藍架
12"Caster
130 mm x 167 mm (5-1/8" x 6-11/16") 100 mm x 140 mm (4" x 5-1/2") 12 mm (1/2")


輪子樣式
固定
Fixed
活動
Swivel
煞車
Brake
200mm x 53mm
(8" x 2-1/8")
120kgs(256 lbs) 風硬輪
Solid Rubber
1117-08-02-1 1117-08-02-2 1117-08-02-4 滾珠
Ball Bearing
245mm
(9-5/8")

活動 163mm
煞車 163mm

Swivel 163mm
Swivel W/Brake 163mm

202mm x 51mm
(8" x 2")
180kgs(400 lbs) 風硬全效輪
Resolute Rubber
1117-08-53-1 1117-08-53-2 1117-08-53-4 滾珠
Ball Bearing
246mm
(9-5/8")
活動 164mm
煞車 164mm

Swivel 164mm
Swivel W/Brake 164mm
208mm x 55mm
(8-3/16" x 2-3/16")
100kgs(220 lbs) 防爆輪
Resolute Rubber
1117-08-05-1 1117-08-05-2 1117-08-05-4 滾珠
Ball Bearing
249mm
(9-13/16")
活動 167mm
煞車 167mm

Swivel 167mm
Swivel W/Brake 167mm
216mm x 65mm
(8-1/2" x 2-9/16")
150kgs(330 lbs) 風輪
Pneumatic
1117-08-01-1 1117-08-01-2 1117-08-01-4 滾珠
Ball Bearing

253mm
(10")

活動 171mm
煞車 171mm

Swivel 171mm
Swivel W/Brake 171mm
246mm x 74mm
(10" x 2-15/16")
230kgs(505 lbs) 風硬W全效輪
W Resolute Rubber
1117-10-95-1 1117-10-95-2 1117-10-95-4 滾珠
Ball Bearing
296 mm
(11-11/16")
活動 199mm
煞車 199mm

Swivel 199mm
Swivel W/Brake 199mm
250mm x 74mm
(10" x 2-15/16")
180kgs(395 lbs) 風硬輪
Solid Rubber
1117-10-02-1 1117-10-02-2 1117-10-02-4 滾珠
Ball Bearing
298 mm
(11-3/4")
活動 201mm
煞車 201mm

Swivel 201mm
Swivel W/Brake 201mm
260mm x 85mm
(10-1/4" x 3-3/8")
150kgs(330 lbs) 防爆輪
Resolute Rubber
1117-10-05-1 1117-10-05-2 1117-10-05-4 滾珠
Ball Bearing
303 mm
(11-15/16")
活動 206mm
煞車 206mm

Swivel 206mm
Swivel W/Brake 206mm
270mm x 86mm
(10-5/8" x 3-3/8")
200kgs(440 lbs) 風輪
Pneumatic
1117-10-01-1 1117-10-01-2 1117-10-01-4 滾珠
Ball Bearing
308 mm
(12-3/16")
活動 211mm
煞車 211mm

Swivel 211mm
Swivel W/Brake 211mm
307mm x 85mm
(12-1/8" x 3-3/8")
250kgs(550 lbs) 風輪
Pneumatic
1117-12-01-1 1117-12-01-2 1117-12-01-4 滾珠
Ball Bearing
350 mm
(13-13/16")
活動 230mm
煞車 230mm

Swivel 230mm
Swivel W/Brake 230mm
